| Overview |
| Dimensions |
212.9 x 113 x 32.5 mm (8.4 x 4.4 x 1.3") |
| WiFi Standard |
WiFi 7 |
| Spatial Streams |
4 |
| Mounting Locations |
Desktop, wall |
| Power Method |
DC jack (54V DC/1.1A) |
| Power Supply |
54V DC/1.1A (Adapter included) |
| Performance |
| MIMO |
|
| 6 GHz |
2 x 2 |
| 5 GHz |
2 x 2 |
| Max. Data Rate |
|
| 6 GHz |
5.8 Gbps (BW320) |
| 5 GHz |
4.3 Gbps (BW240) |
| Antenna Gain |
|
| 6 GHz |
8 dBi |
| 5 GHz |
8 dBi |
| Max. TX Power |
|
| 6 GHz |
23 dBm |
| 5 GHz |
26 dBm |
| Max. Conducted TX Power |
26 dBm (Combined) |
| Supported Data Rates |
|
| 802.11be (WiFi 7) |
6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320)
5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240) |
| 802.11ax (WiFi 6) |
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) |
| 802.11ac (WiFi 5) |
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) |
| 802.11n |
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
| 802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Wireless Security |
WPA3 SAE (Always On) |
| Hardware |
| Max. Power Consumption |
25W (Excluding PoE output) |
| Supported Voltage Range |
42.5—57V DC |
| Networking Interface |
(1) 10 GbE RJ45 port
(7) 2.5 GbE RJ45 ports |
| PoE Interface |
(8) PoE+ ports |
| Max. PoE Wattage per Port |
30W |
| Total PoE Availability |
60W AC adapter input: 35W
210W AC adapter input: 185W |
| Antennas |
(1) Internal |
| Management |
| Ethernet |
|
| WiFi |
|
| Channel Bandwidth |
20/40/80/160/240/320 MHz |
| Weight |
Device: 548 g (1.21 lb)
With mount: 563 g (1.24 lb) |
| Enclosure Material |
Polycarbonate |
| Mount Material |
Polycarbonate |
| LCM Display |
0.96" status display |
| Button |
(1) Factory-reset |
| NDAA Compliant |
Yes |
| Certifications |
CE, FCC, IC |
| Operating Frequency |
|
| Worldwide |
5150—5875 MHz
5945—7125 MHz |
| Ambient Operating Temperature |
-30 to 40° C (-22 to 104° F) |
| Ambient Operating Humidity |
5 to 95% noncondensing |
| Software |
| Application Requirements |
UniFi Network |
| Minimum Version |
Version 10.0.156 or later |
