Ubiquiti Networks UniFi in-Wall Wi-Fi Access Point 802.11AC Wave 2 - Daanish Technologies
Ubiquiti Networks UniFi in-Wall Wi-Fi Access Point 802.11AC Wave 2 - Daanish Technologies

[UAP-IW-HD] Ubiquiti UniFi in-Wall Wi-Fi Access Point 802.11AC Wave 2

Add wireless connectivity to your in-wall Ethernet outlet with the UniFi IW HD In-Wall Wi-Fi Access Point from Ubiquiti. Ideal for high-density environments like hotels and meeting rooms, the dual-band UniFi IW HD access point supports Wi-Fi 5 (802.11ac) Wave 2 and multi-user MIMO wireless technology, which allows for simultaneous connections with multiple clients. Wall-mounted WiFi 5 AP with 6 spatial streams and a built-in 4-port switch ideal for single-room coverage in hospitality environments. WiFi 5 6 spatial streams 90 m² (1,000 ft²) coverage 200+ connected devices Powered using PoE/PoE+* (4) GbE ports with (1) PoE output GbE uplink Installation Guide: Documentation   ...
Vendor: Ubiquiti
SKU: UAP-IW-HD
Availability: Out Of Stock
Product Type: Access Point
$179.00
$179.00
Subtotal: $179.00
Ubiquiti Networks UniFi in-Wall Wi-Fi Access Point 802.11AC Wave 2 - Daanish Technologies

[UAP-IW-HD] Ubiquiti UniFi in-Wall Wi-Fi Access Point 802.11AC Wave 2

$179.00
Ubiquiti Networks UniFi in-Wall Wi-Fi Access Point 802.11AC Wave 2 - Daanish Technologies

[UAP-IW-HD] Ubiquiti UniFi in-Wall Wi-Fi Access Point 802.11AC Wave 2

$179.00
Description & Technical Specification

Add wireless connectivity to your in-wall Ethernet outlet with the UniFi IW HD In-Wall Wi-Fi Access Point from Ubiquiti. Ideal for high-density environments like hotels and meeting rooms, the dual-band UniFi IW HD access point supports Wi-Fi 5 (802.11ac) Wave 2 and multi-user MIMO wireless technology, which allows for simultaneous connections with multiple clients.

Wall-mounted WiFi 5 AP with 6 spatial streams and a built-in 4-port switch ideal for single-room coverage in hospitality environments.

WiFi 5

6 spatial streams

90 m² (1,000 ft²) coverage

200+ connected devices

Powered using PoE/PoE+*

(4) GbE ports with (1) PoE output

GbE uplink

Installation Guide:

Documentation



Technical Specifications:



MECHNICAL

Dimensions

139.7 x 86.7 x 25.8 mm (5.5 x 3.4 x 1")

Weight

 210 g (7.4 oz)


HARDWARE

Management interface

Ethernet

Networking interface

 (5) GbE RJ45 ports

PoE interface

 (1) PoE/PoE+ in
(1) PoE out

Power method

 PoE
PoE+(Required for PoE passthrough)

Power supply

UniFi PoE switch

PoE out

48V pass-through (Pins 1, 2+; 3, 6-)

Supported voltage range

44—57V DC

Max. power consumption

11W (Excluding PoE output)

Max. PoE wattage per port by PSE

23W*
*Requires PoE switch.

Max. TX power
2.4 GHz
5 GHz

23 dBm
26 dBm

MIMO
2.4 GHz
5 GHz

2 x 2 (DL MU-MIMO)
4 x 4 (DL MU-MIMO)

Max. data rate
2.4 GHz
5 GHz

300 Mbps (BW40)
1.7 Gbps (BW80)

Antenna gain
2.4 GHz
5 GHz

1.8 dBi
6 dBi

Button

Factory reset

Mounting

 1-Gang electrical wall box (Optional)

Ambient operating temperature

-10 to 60° C (14 to 140° F)

Ambient operating humidity

 5 to 95% Noncondensing

Certifications

CE, FCC, IC, cULus


SOFTWARE

WiFi standards

802.11a/b/g/n/ac

Wireless security

WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11w/PMF

BSSID

Up to 8 per radio

VLAN

 802.1Q

Advanced QoS

 Per-user rate limiting

Guest traffic isolation

Supported

Power save

Supported

Beam-forming

Supported

WMM

 Voice, video, best effort, and background

Concurrent clients

200+


SUPPORTED DATA RATES

802.11a

6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b

1, 2, 5.5, 11 Mbps

802.11g

6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n

6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

802.11ac

 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80)
58 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 160)
